Operating Voltage

99.6-35V DC (Protection under battery voltage of

Current Drawn

2X850mA for each LED

Driving Method

PWM current and voltage controlled driver

Driver Feature

LED connection is independent from the battery pole

Control Method

5 different Modes with Push Drop Button

 MOD1: Direct fog lamp Feature

 MOD2: fog lamp DİM1

 MOD3: fog lamp DİM2

 MOD4: fog lamp Flash Mode

 MOD5: SOS Mode

 MOD6: Closing Mode

Initial Operation Mode

Fog lamp is activated when ignition is started

Warning LED Feature

Separate warning for each mode

Physical Specifications

Plastic ABS Body

Standards

SAE J 1849 - 1113-41 IP 67

Dimensions

(A-10,5cm) (B-6cm) (C - 3,2cm)

Weight

77gr

Chassis Color

Black
